Profile Teeb Sawb
Siv lub siab zoo thiab lub siab ci ci hom nti;
Tsawg xim kub kam rau ua (MacAdam<5);
Tsawg voltage poob-2oz PCB;
Kev tiv thaiv ib puag ncig thiab UV rays;
Ntau yam kev siv xws li kev lag luam teeb pom kev zoo, teeb pom kev sab nraum zoov.
- Product Introduction
|
Qauv No |
WMD-LR10100NB012 LED Neon Teeb Sawb (Sab saum toj khoov) |
|
Qhov hluav taws xob |
DC 24 V |
|
Hwj chim |
6/12W (± 10%) |
|
LED hom |
SMD2835: Cree, Lumileds Samsung, Osram yeem |
|
Led / m |
120 LEDs / M |
|
Luminous flux |
>600lm（P=12W/M）4000K,Ra>90） |
|
Lub teeb efficiency |
>50lm/W（P=12W/M,4000K,Ra>90） |
|
CRI |
Ra>90 |
|
Beam Angle |
120 degree |
|
IP |
IP65 |
|
PCB |
8mm ib |
|
Xim |
2700/3000K（±150K）,3500K/4000K（±200）,6000K（±500） |
|
Khoom siv |
Khoom noj khoom haus-qib ib puag ncig tus phooj ywg silicone |
|
Xim kam rau ua |
SDCM 5 |
|
Khoom dimension |
L5015 * W10 * H10mm (5M / Reel) |
|
Tswj hom |
ON/OFF, 0-10V Dimmer |
|
Kev teeb tsa |
AL Clip/slot (4.0mm ntsia hlau qhov) |
|
Hom kev tawm sab nraud |
Hlau qhov hluav taws xob ntawm ob qho kawg: liab qab hlau, tsis muaj dej txuas, 2 * 0.75mm² silicone hlau, ntev L300mm |
|
Ntim |
Sab hauv thiab sab nrauv lub thawv; 14pcs / lub thawv, lub thawv loj: 415 * 415 * 230mm |
Khoom loj:
| Lub cev loj | Qhov loj me |
 |
 |
Ncaj nraim
Sab kab
Hauv qab kab
*unit:mm *Qhov loj ntawm lub teeb siv / clip yog ± 0.3mm
Qhov zoo:
►Siv lub siab zoo thiab lub siab ci hom nti;
► Tsawg xim kub kam rau ua (MacAdam<5);
► Tsawg voltage poob -2oz PCB;
► Muaj kev tiv thaiv ib puag ncig thiab UV rays;
► Kev cai ntev muaj.
Daim ntawv thov:
Accent teeb pom kev zoo, kev lag luam teeb pom kev lag luam, teeb pom kev sab nraum zoov.
Vim li cas thiaj xaiv peb?
- Peb Cov Teeb Teeb Teeb yog qhov ruaj khov thiab xav tau kev saib xyuas tsawg.
- Peb cog lus tias yuav ua raws li txhua txoj cai thiab kev tswj hwm, thiab ua lub luag haujlwm rau peb cov lus thiab kev ua, ua tiav peb lub luag haujlwm thiab siv zog ua haujlwm thiab ua tiav.
- Peb yog ib qho chaw nres tsheb rau txhua qhov koj xav tau Strip Light.
- Nws yog peb qhov kev nrhiav tsis tu ncua los txhim kho cov kev sib tw tseem ceeb ntawm kev lag luam thiab tsim kev lag luam zoo.
- Peb siv zog ua kom muaj txiaj ntsig zoo rau ib puag ncig nrog peb Cov Teeb Teeb Teeb.
- Qhov tseem ceeb ntawm kev sib tw ntawm cov khoom nyob rau hauv nws qhov zoo, thiab yog tias peb tsis txiav cov fab ntawm qhov zoo, peb yuav yeej qhov kev ntseeg siab thiab kev txhawb nqa ntawm peb cov neeg siv khoom.
- Peb mob siab rau kev ua tau zoo hauv txhua yam peb ua, suav nrog peb Cov Teeb Teeb.
- Nyob rau hauv peb lub xyoo ntawm hom kev loj hlob keeb kwm, peb tau hais kom tsim kom muaj kev ua tau zoo ntawm Profile Light Strip nrog ua lub zog thev naus laus zis.
- Peb muaj kev txaus siab nyob rau hauv kev xa cov Sawb Teeb uas tsis muaj qhov thib ob.
- Peb lub tuam txhab muaj kev tswj xyuas kev ua tiav thiab kev tshawb fawb zoo, cov cuab yeej siv high-tech ntau lawm, thiab pab pawg kws tshaj lij kws pab tswv yim.
Taw qhia
Profile Light Strip yog ib yam khoom tshwj xeeb thiab tsim tshiab uas yog tsim los muab kev pom kev pom hauv ntau qhov chaw. Raws li cov chaw tsim khoom nyob rau hauv Suav teb, peb zoo siab los nthuav qhia peb cov khoom tshiab tsim los ua kom tau raws li cov kev xav tau ntawm cov lag luam thiab cov tib neeg thoob ntiaj teb. Peb Profile Lub Teeb Sawb yog qhov ua tau zoo, kev siv nyiaj txiag, thiab kev daws teeb meem eco-friendly uas muaj ntau yam txiaj ntsig rau cov neeg siv khoom nrhiav cov teeb pom kev zoo thiab txhim khu kev qha.
Tsim thiab Nta
Profile Light Strip yog cov teeb pom kev zoo ntau yam uas tuaj yeem siv rau hauv ntau qhov chaw, suav nrog tsev, chaw ua haujlwm, thiab cov khoom lag luam. Nws yog tsim los nrog lub compact thiab slim profile uas ua rau nws yooj yim rau nruab rau hauv txhua qhov chaw. Lub teeb sawb nta tus qauv tsim tshwj xeeb uas ua kom pom tseeb txawm tias qhov pom kev, ua rau nws zoo tagnrho rau kev siv hauv thaj chaw uas xav tau teeb pom kev zoo.
Peb Profile Lub Teeb Sawb muaj nyob rau hauv ntau yam xim, nrog rau sov dawb, txias dawb, thiab RGB. Qhov no txhais tau hais tias cov neeg siv khoom tuaj yeem xaiv cov xim uas haum rau lawv cov kev xav tau thiab nyiam. Tsis tas li ntawd, lub teeb sawb yog txawm peem rau nrog ib tug dimming muaj nuj nqi, uas tso cai rau cov neeg siv los kho qhov siv ntawm lub teeb raws li xav tau.
Lub Profile Lub Teeb Sawb kuj tseem siv zog, siv tsuas yog ib feem ntawm lub zog xav tau los ntawm cov teeb pom kev zoo ib txwm siv. Nws siv high-zoo LED chips uas muab kev ntseeg siab thiab ua haujlwm ntev. Lub teeb sawb kuj tau nruab nrog IP65 ntsuas dej tsis zoo, ua rau nws tsim nyog siv ob qho tib si sab hauv tsev thiab sab nraum zoov.
Daim ntawv thov
Peb Profile Lub Teeb Sawb yog cov khoom siv ntau yam uas tuaj yeem siv rau ntau yam kev siv. Nov yog qee qhov kev siv ntau tshaj plaws rau peb cov khoom:
1. Illuminating Sab Hauv Qhov Chaw: Lub Profile Lub Teeb Sawb yog qhov kev xaiv zoo rau kev teeb pom kev sab hauv, nrog rau tsev, chaw ua haujlwm, khw muag khoom, thiab lwm yam. Nws tuaj yeem ntsia tau rau hauv qab nthab, phab ntsa, thiab lwm qhov chaw los muab cov teeb pom kev zoo thiab ci ntsa iab.
2. Highlighting Decorative Elements: Lub Profile Lub Teeb Sawb tuaj yeem siv los qhia cov khoom zoo nkauj hauv tsev thiab cov khoom lag luam. Piv txwv li, nws tuaj yeem ntsia tau rau hauv cov txee, cov txee, thiab lwm qhov chaw kom pom cov duab kos duab, phau ntawv, thiab lwm yam khoom zoo nkauj.
3. Sab nraum zoov Teeb pom kev zoo: Ua tsaug rau nws qhov ntsuas IP65 tsis muaj dej tsis zoo, Profile Light Strip tuaj yeem siv rau sab nraum zoov teeb pom kev zoo. Nws yog qhov zoo tagnrho rau kev teeb pom kev, taug kev, thiab lwm qhov chaw sab nraum zoov.
4. Daim Ntawv Thov Kev Lag Luam: Cov Profile Light Strip yog ib qho kev xaiv zoo thiab txhim khu kev qha rau cov teeb pom kev zoo hauv cov khoom lag luam. Nws tuaj yeem siv rau hauv khw muag khoom, khw noj mov, thiab lwm yam lag luam los muab kev pom zoo rau cov neeg siv khoom thiab cov neeg ua haujlwm.
Xaus
Zuag qhia tag nrho, peb Profile Light Strip yog ntau yam thiab cov teeb pom kev zoo tshiab uas muaj ntau yam txiaj ntsig rau cov neeg siv khoom. Txawm hais tias koj tab tom nrhiav tus nqi-zoo thiab eco-phooj ywg teeb pom kev zoo rau koj lub tsev lossis kev lag luam, peb cov khoom yog cov kev daws teeb meem zoo tshaj plaws. Nrog nws cov qauv tsim, txawm tias lub teeb pom kev zoo, thiab kev ua haujlwm zoo ntawm lub zog, Profile Light Strip yog qhov tseeb kom ua tau raws li koj cov kev xav tau rau cov teeb pom kev zoo thiab kav ntev. Yog li vim li cas tos? Tiv tauj peb hnub no kom paub ntau ntxiv txog peb cov khoom thiab nws yuav pab tau koj li kev lag luam lossis tsev.
